SK08110• Multi-level turn-off
• Digitally controlled active clamping
• Intelligent fault management
| Product | Max Breakdown Voltage | Module Housing | Supported Module（s） | IGBT Manufacturer | Supported Module Type | Gate Turn-on Voltage | Gate Turn-off Voltage | Supported Topologies | Protection Features | Supply Voltage(Typ) | Power-Ouput/Channels(Max) | Connection Type to IGBT | Driving Mode | Gate Peak Current（Max） | Interface Type | Logic Input Voltage | Max Switching Frequecy | Numebers of Channels | Temperature-operating（Max） | Temperature-operating（Min） | Temperature-Storage（Max） | Temperature-Storage（Min） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SK08110V-A1 | 6500V | IHV | FZ1200R45KL3 5SNA3000K452300 | Infineon | IGBT | 15V | -10V | 2-level, multi-level | di/dt, Undervoltage, Soft shut down, Multi-level turn-on, Multi-level turn-off, Advanced active clamping, Highly robust DC/DC, Over-temperature | 15V | 8W | / | Direct | 110A | Optical | / | 5kHz | 1 | 85℃ | -40℃ | 85℃ | -40℃ |
| SK08110-A1 | 6500V | IHV | FZ750R65KE3 | Infineon | IGBT | 15V | -10V | 2-level, multi-level | di/dt, Undervoltage, Soft shut down, Multi-level turn-on, Multi-level turn-off, Advanced active clamping, Highly robust DC/DC, Over-temperature | 15V | 8W | / | Direct | 110A | Optical | / | 5kHz | 1 | 85℃ | -40℃ | 85℃ | -40℃ |
Product Information
Product Details
The SK08110 is a high-end gate driver developed for crimp modules in high reliability fields such as HVDC and offshore wind power. Through the combination of Firstack's unique "digitally controlled active clamping" and "multi-level turn-off" technology, the module can be safely shut down with any large current under the commutation loop of 200+nH stray inductance.
Highly Functional and Reliable
Plug-and-play gate driver solution for up to 6500V Press-Pack IGBT
15V gate voltage in on-state
8W output power per channel at maximum ambient temperature
110A gate peak current
Short-circuit protection by Vce monitoring
Optical interface
-40°C to 85°C operating ambient temperature
Intelligent fault management
Protection
Undervoltage protection
Muti-level turn-off
Vce monitoring
di/dt protection
Active clamping
Highly robust DC/DC
Safety Segregation Standard
IEC 60747-1 Chapter 1
Level-2 protection
