HV1027P• Highly robust DC/DC
• Double short-circuit protection: di/dt+VCE desaturation
• Integrates multi-level turn-on and turn-off technology
• Intelligent fault management
| Product | Max Breakdown Voltage | Module Housing | Supported Module（s） | IGBT Manufacturer | Supported Module Type | Gate Turn-on Voltage | Gate Turn-off Voltage | Supported Topologies | Protection Features | Supply Voltage(Typ) | Power-Ouput/Channels(Max) | Connection Type to IGBT | Driving Mode | Gate Peak Current（Max） | Interface Type | Logic Input Voltage | Max Switching Frequecy | Numebers of Channels | Temperature-operating（Max） | Temperature-operating（Min） | Temperature-Storage（Max） | Temperature-Storage（Min） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HV1027P-2V-45-A1 | 4500V | IHV | All | Infineon and so on | IGBT | 15V | -9.5V | 2-level, multi-level | Vce detection, Undervoltage, Active clamping, Soft shut down, Multi-level turn-off, Highly robust DC/DC | 15V | 3W | / | Direct | 27A | Optical | / | 5kHz | 1 | 85℃ | -40℃ | 85℃ | -40℃ |
| HV1027P-2V-65-A1 | 6500V | IHV | All | Infineon and so on | IGBT | 15V | -9.5V | 2-level, multi-level | Vce detection, Undervoltage, Active clamping, Soft shut down, Multi-level turn-off, Highly robust DC/DC | 15V | 3W | / | Direct | 27A | Optical | / | 5kHz | 1 | 85℃ | -40℃ | 85℃ | -40℃ |
Product Information
Product Details
The HV1027P series are plug-and-play drivers based on Firstack digital intelligent IGBT gate drivers, which are specially developed for IHV package. They are suitable for 4500V and 6500V IGBT modules, and have the advantages of powerful functions, high reliability and good EMC characteristics. They apply for 2-level and multi-level topologies.
Highly Functional and Reliable
Plug-and-play gate driver solution for up to 6500V IHV IGBT
15V gate voltage in on-state
3W output power per channel at maximum ambient temperature
-30A/+27A gate peak current
Short-circuit protection by Vce monitoring
Optical interface
-40°C to 85°C operating ambient temperature
Intelligent fault management
Protection
Undervoltage protection
Muti-level turn-off
Vce monitoring
di/dt protection
Active clamping
Highly robust DC/DC
Safety Segregation Standard
IEC 60747-1 Chapter 1
Level-2 protection
